High Intelligibility Voice Reinforcement

Overview

AX8 is a powerful and effective combination of high performance, lightweight design and natural simplicity.

This high bandwidth, high efficiency, horn loaded 8'' loudspeaker is the perfect choice for demanding speech applications where quality of vocal intelligibility is paramount. This loudspeaker is highly durable and weather resistant and is supplied complete with a versatile mounting bracket and stainless steel grille.

PERFORMANCE FEATURES

High intelligibility speech loudspeaker

  • 1
    Exceptional speech intelligibility
  • 2
    Wide bandwidth 8'' eliminates need for 1'' compression driver and passive crossover network
  • 3
    Lightweight and high durability
  • 4
    Funktion-One designed weather resistant driver
  • 5
    Optional stainless steel mounting yoke and fixings
  • 6
    Normally fitted with length of tough PU sheathed cable
  • 7
    100V Line version available

Technical Specification

Driver 8"
Operating Band 180Hz - 8kHz
Sensitivity at 1m 109dB at 4V
Power (AES) 200W
Nominal Impedence 16Ω
USABLE BANDWIDTH (-3DB) 180Hz - 8kHz
Weight 50° Horizontal x 25° Vertical
Nominal Dispersion 13.5kg (30 lbs)
Connectors Glanded captive lead
